| Fitting position | front axle |
| Height (mm) | 77 |
| Outer diameter (mm) | 276 |
| Bolt hole circle Ø (mm) | 130 |
| Quantity required | 2 |
| Num. of holes | 5 |
| Wheel bolt bore Ø (mm) | 15 |
| Brake disc thickness (mm) | 22 |
| Centering diameter (mm) | 85 |
| Min. thickness (mm) | 19 |
| Brake disc type | vented |
| Manufacturer | Productnumber |
| mercedes-benz | 901 421 03 12 , 9014210312 |
| mercedes-benz | 902 421 03 12 , 9024210312 |
| mercedes-benz | 902 421 04 12 , 9024210412 |
| mercedes-benz | 902 421 06 12 , 9024210612 |
| mercedes-benz | 902 421 07 12 , 9024210712 |
| mercedes-benz | 902 421 09 12 , 9024210912 |
| mercedes-benz | A 901 421 03 12 , A9014210312 |
| mercedes-benz | A 902 421 03 12 , A9024210312 |
| mercedes-benz | A 902 421 04 12 , A9024210412 |
| mercedes-benz | A 902 421 06 12 , A9024210612 |
| mercedes-benz | A 902 421 07 12 , A9024210712 |
| mercedes-benz | A 902 421 09 12 , A9024210912 |
| vw | 2D0 615 301 A , 2D0615301A |
| vw | 2D0 615 301 B , 2D0615301B |
| vw | 2D0 615 301 C , 2D0615301C |
| vw | 2D0 615 301 D , 2D0615301D |
| vw | 2D0 615 601 E , 2D0615601E |
| Usage numbers |
| MBD0036 |
| A.B.S. 16453 |
| A.B.S. 17346 |
| APEC DSK 771 |
| APEC SDK6104 |
| ATE 24.0122-0161.1 |
| ATE 24.0322-0161.1 |
| BARUM BAR22161 |
| BENDIX 562086B |
| BENDIX 562086BC |
| BENDIX 562120B |
| BLUE PRINT ADU174360 |
| BORG & BECK BBD5081 |
| BORG & BECK BBD5134 |
| BOSCH 0 986 478 849 |
| BREMBO 09.7314.14 |
| BREMBO 09.7314.24 |
| BREMBO 09.9618.14 |
| BREMBO 09.9618.24 |
| COMLINE ADC1610V |
| COMLINE ADC1618 |
| COMLINE AND6110 |
| DELPHI BG3194 |
| DELPHI BG3236 |
| DELPHI BG3236C |
| DT Spare Parts 4.63998 |
| FEBI BILSTEIN 07517 |
| FEBI BILSTEIN 22857 |
| FERODO FCR153A |
| FERODO FCR228A |
| FTE BS4544 |
| FTE BS4544B |
| GIRLING 6027901 |
| HELLA 8DD 355 110-991 |
| HELLA 8DD 355 111-001 |
| HELLA PAGID 54315 |
| HELLA PAGID 54315PRO |
| HELLA PAGID 54315PRO_HC |
| HELLA PAGID 8DD 355 110-991 |
| HELLA PAGID 8DD 355 111-001 |
| HELLA PAGID 8DD 355 128-251 |
| ICER 78BD0181-1 |
| ICER 78BD0186-1 |
| JAPANPARTS DI-0561 |
| JAPANPARTS DI-0561C |
| JURID 561965J |
| JURID 562086JC |
| JURID 567760J |
| JURID 569122J |
| LEMFÖRDER 22220 03 |
| LEMFÖRDER 31233 01 |
| LPR M2561V |
| METELLI 23-0418 |
| MEYLE 015 521 2038 |
| MEYLE 083 521 2032/PD |
| MEYLE MBD0040 |
| MINTEX MDC1036 |
| MINTEX MDC1037 |
| MINTEX MDC1037C |
| NK 203334 |
| NK 203377 |
| NK 203397 |
| NK 313397 |
| NK BS-4611 |
| OPEN PARTS BDA1706.20 |
| OPTIMAL BS-4611 |
| OPTIMAL BS-7290 |
| OPTIMAL BS-7290HC |
| REMSA 6461.10 |
| ROADHOUSE 6461.10 |
| sbs 1815203397 |
| sbs 1815313397 |
| SWAG 10 90 7517 |
| SWAG 10 92 2857 |
| TEXTAR 92105400 |
| TEXTAR 92131500 |
| TEXTAR 92131503 |
| TRISCAN 8120 10169 |
| TRUCKTEC AUTOMOTIVE 02.35.025 |
| TRUSTING DF506 |
| TRW DF2790 |
| TRW DF4321 |
| VAICO V10-80013 |
| VAICO V30-80053 |
| VALEO 186774 |
| VALEO 187041 |
| VALEO 187121 |
| VALEO 672571 |
| ZIMMERMANN 400.1441.20 |
| ZIMMERMANN 400.6470.20 |
| Manufacturer | Model | Version | Engine code | Construction type | Construction start | Construction end | Pk | Power kw |
 mercedes-benz |
||||||||
 vw |
All our standard discs are priced individually, but due to the safety critical aspect of the braking system, Brake Discs must now be purchased in pairs where required and we will add a quantity of 2 to your basket. (Some high-performance discs are sold as a set of two). Our brake pads are sold as a front set or rear set, so purchasing one box will be enough for two discs
See the diameter on the right side of the product image .The best way to ensure you get the correct brake discs is to check the diameter of the brake discs already fitted.
Simply enter your vehicle registration or VIN on our website. Our built-in system will automatically show you the correct brake discs for your car. You can also message us if you need help.
On average, brake discs last between 30,000–70,000 miles, but this varies based on driving style and conditions. Look out for signs like vibrations, noise, or visible wear.
All our brake discs are brand new and meet or exceed OEM standards.
